| The Marine Guardian RCM aerial meter series is a new generation of aerial meter developed based on the Marine Guardian data recording platform and the ZPulse Doppler current sensor.Modern computer technology combined with advanced digital signal processing technology can provide high resolution, accurate and detailed measurements, with measurement parameters including temperature, pressure (depth), conductivity, dissolved oxygen, waves, and tides. |  |
| Features |
| 1. Built-in data storage and large storage capacity of SD card |
| 2. Intelligent sensor, plug and play |
| 3. Includes Andra's real-time data acquisition software visual data processing software |
| 4. Can connect up to 4 analog (0-5V) sensors |
| 5. Broadband multi-frequency ZPulse technology improves data quality and sampling speed and reduces power consumption |
| 6. Windows CE-based data logger and TFT technology-based color touch screen for field settings |
| 7. Used for oceans and freshwater |
|
| The Marine Guardian RCM series is an upgraded version of the traditional Marine Guardian RCM 9 and RCM11.It has been redesigned from the top down, with state-of-the-art technology in both digital generator and sensor solutions. |
| The Marine Guardian system is a perfect fusion of a universal digital receiver unit and a set of autonomous intelligent sensors.The digital generator and smart sensor use a reliable CANbus bus interface connection, using XML data format to achieve plug-and-play functions.When powered on, each sensor connected to the bus will report its performance and specifications to the digital generator.The digital generator collects sensor information and then provides the customer with optional configuration options based on the accessed sensor conditions.This solution provides great flexibility for the use and design of different elements in the system. |
| Because on the one hand, the intelligent sensor can work independently, and on the other hand, it can be freely connected to the Ocean Guard system, this allows sensor designers to have more flexibility when designing sensor optimization based on sensor application, without considering sensor optimization to the entire systemThe burden brought.The system data is stored on the SD card, with a storage capacity of 2GB, which is sufficient.The Ocean Guardian platform has a built-in current calculator, which can calculate the long-term deployment time of the entire system based on information such as measurement interval, battery type, and the power consumption of smart sensors. |
| The Marine Guardian RCM is equipped with a ZPulse multi-frequency Doppler current sensor standard.This technology improves the statistical accuracy of the measurement and reduces the number of pings required for specific statistical errors, thus increasing sampling speed and saving power consumption. |
| The sensor also integrates a powerful electronic compass and tilt sensor.Other Marine GuardianRCMNew generations of smart sensors such as temperature, conductivity and dissolved oxygen can also be integrated.Compared with previous models, the new generation of sensor resolution has been improved. |
